600 Tons 36 Openings Hot Press With Loadig System

Best quality,good price and nice after-sales for you.

Availability:
Quantity:

Plywood Hot Press Machine

Plywood is a wood-based panel product comprised of a collection of veneers that are glued together with a resin. To sum up the production process; logs are peeled into veneers, the veneers are lathered in glue, laid up so that the grain direction of each veneer is perpendicular to its adjacent veneer, pressed together, trimmed and sanded.


We are ISO 9001-2008 certified , each managing flow is strictly according to the certification , Purchase , Finance and Warehouse Stock . All the parts including the electric parts , motors , knives are from famous brand companies .


Our company is specialized in the woodworking machine for many years and release a newly product each year. This year, we will release automatic loading system of hot press and cold press which advances the development and help the customers to save much more manual and material resources.


Our company  also help the customers to plan a new factory or update the old production line for new .The plywood factory we have to help us to get much more experiences to update our woodworking machine, so we can give you the technological guidance of producing plywood and machine. The strong technology team we also have to make our company further progress.


Please trust us ,we would give you the best.

Specification

Model:XHC36-36-2-360-42-80

36Opening 500T

Total pressure

500T

Board feeding direction

Transverse

Layers

36 layers

Layer spacing

80MM

Hot press plate

Number of hot press plate:37pcs

Size

1050*2100*42(single inlet and outlet)

Material

Q235

Cylinder   for hot press machine

2*360mm

Seal

4pcs rubber seals   per pcs of cylinder

Stroke

1200mm

Hydraulic system for hot press machine

Compression   resistance:25Mpa

Low pressure pump flowing

315ML/R

High pressure pump flowing

31ML/R

Motor power

15kw+15kw+15kw

Closing time

15s

Overall dimension

3555*1350*5486mm

Weight

About 56T


hot pressing
