Cold press machine is the auxiliary in plywood production line, which is used to shorten the cycle time of hot press and improve the quality of plywood before gluing board. Cold press machine belongs to the pressing machine. Cold press machine is mainly used to press the gluing veneer, so that make the initial shape, and then into the hot press machine to press. It is important to improve the quality of plywood, and it is an significant part. Cold press machine in general consists with the rack, fixed beam, moving beam, the plate device, cylinder and hydraulic system, control device components.
Plywood Cold Press Machine | ||
1 | Nominalgross pressure | 400Tons500Tons600Tons |
2 | Nominal Oil pressure | 25Mpa |
3 | Numberof cylinder | 2 |
4 | Place of cylinder | Top |
5 | Size of hot press plate | 1370*2700 |
6 | Diameter of cylinder | 320mm |
7 | Stroke of cylinder | 1050 |
8 | Oil cylinder | 80mm*2 |
9 | High pressure pump flow | 25M |
10 | Power Motor | 11kw |
11 | Dimension | 3600*1370*4600mm |
12 | Thickness of steel | 30mm |
13 | Opening | 1800mm |
14 | Framework | Combined frame |
15 | Total weight | About12T | 13T | 17T |
1. Adopting national standard H steel and channel steel to ensure that the rack is sturdy and durable.
2. Precision platen working table,It can make the pressure distribution of the whole table evenly and the flatness of the pressure maintaining surface for a long time.
3. Timing control,Set the appropriate time, when the set time is reached, the pressure plate will automatically release and beep to remind the operator.
4. The circuit is set with overload protection, short circuit protection, loss of voltage protection and undervoltage protection.
Cold press machine is the auxiliary in plywood production line, which is used to shorten the cycle time of hot press and improve the quality of plywood before gluing board. Cold press machine belongs to the pressing machine. Cold press machine is mainly used to press the gluing veneer, so that make the initial shape, and then into the hot press machine to press. It is important to improve the quality of plywood, and it is an significant part. Cold press machine in general consists with the rack, fixed beam, moving beam, the plate device, cylinder and hydraulic system, control device components.
Plywood Cold Press Machine | ||
1 | Nominalgross pressure | 400Tons500Tons600Tons |
2 | Nominal Oil pressure | 25Mpa |
3 | Numberof cylinder | 2 |
4 | Place of cylinder | Top |
5 | Size of hot press plate | 1370*2700 |
6 | Diameter of cylinder | 320mm |
7 | Stroke of cylinder | 1050 |
8 | Oil cylinder | 80mm*2 |
9 | High pressure pump flow | 25M |
10 | Power Motor | 11kw |
11 | Dimension | 3600*1370*4600mm |
12 | Thickness of steel | 30mm |
13 | Opening | 1800mm |
14 | Framework | Combined frame |
15 | Total weight | About12T | 13T | 17T |
1. Adopting national standard H steel and channel steel to ensure that the rack is sturdy and durable.
2. Precision platen working table,It can make the pressure distribution of the whole table evenly and the flatness of the pressure maintaining surface for a long time.
3. Timing control,Set the appropriate time, when the set time is reached, the pressure plate will automatically release and beep to remind the operator.
4. The circuit is set with overload protection, short circuit protection, loss of voltage protection and undervoltage protection.
